Scout Locator

Red

ABS

PAL model

Uses multi-directional locating technology to solve the most demanding remote transmitter (sonde) locates

Locates SeeSnake in-line transmitters, remote transmitters (sondes), and energized metallic lines

Transmitters can be approached from any direction, resulting in faster, more accurate locates

Distinctive on-screen markers guide you to the target

Locate can be easily verified using large mapping display

Depth is automatically calculated and displayed when over the target

Displays real-time signal strength with no need to adjust gain

Powerful and compact design weighs only 3 lbs.

Multi-directional antenna eliminates false peaks

Ideal for users locating SeeSnake cameras and other sondes (both sold separately) who occasionally need to locate energized lines

Standard Frequencies:
Sonde: 16 Hz, 512 Hz, 640 Hz, 874 kHz and 33 kHz
Line Trace: 128 Hz, 1 kHz, 8 kHz and 33 kHz
Passive AC Line Trace: 60 Hz, 50 Hz

Meets FCC Class B and EN 55022 Class B Requirements

Power Source: 4 C-Cell batteries or Rechargeable RIDGID Professional 18V battery with RIDGID SeekTech 18V Adaptor (optional)
Battery Life: Varies with battery rating, use and operating factors. Four size C, alkaline batteries provide approximately 12 to 24 hours
